Product Description:
Material Properties
The primary materials used in mainstream products are thermoplastic elastomers (TPE). However, alternative materials such as EPDM (Ethylene Propylene Diene Monomer) rubber and Viton (fluororubber) are available upon request to meet specific needs. TPE stands out for its excellent tensile strength, achieved without the need for fabric reinforcement, and is produced through precision injection molding. This material offers notable flexibility, allowing it to withstand frequent opening and closing actions while maintaining reliable sealing capabilities. Its cost-effectiveness makes it an ideal choice for most industrial dust removal applications.
In contrast, EPDM and Viton materials are selected for specialized environments that demand resistance to high temperatures or corrosive substances. Additionally, certain maintenance kits incorporate both primary and secondary diaphragms to enhance sealing reliability and operational stability.
Operating Parameter Properties
The operating pressure for these components aligns with the pulse valve's pressure range of 0.4 to 8 bar. Within this spectrum, stable and consistent opening and closing actions ensure the pulse air flow generates sufficient impact force to efficiently clear dust from filter bags.
Temperature resistance is another key attribute, with the ability to handle medium temperatures from -40℃ to +85℃ and ambient temperatures ranging from -20℃ to +85℃. This adaptability allows the material to perform reliably under varying temperature conditions commonly found in industrial settings without becoming brittle or deforming.
Thanks to the superior quality of TPE coupled with precise manufacturing processes, the service life of these materials can reach up to one million operating cycles. This longevity substantially decreases the frequency of equipment maintenance and replacement, offering significant operational advantages.
Functional and Performance Properties
Serving as the sole moving component of the pulse valve, the diaphragm plays a critical role by executing rapid opening and closing motions that generate shock air waves. These waves effectively dislodge dust accumulated on filter bags. The diaphragm also maintains a high flow rate, which contributes to efficient dust cleaning and quick responsiveness, ensuring that the pulse valve functions economically and reliably.
The sealing properties of the TPE material are outstanding. When combined with the diaphragm's structural design, it successfully prevents gas leakage and exhibits a level of resistance against contamination. This helps minimize the impact of impurities on sealing performance. Furthermore, specific exhaust designs featuring threaded interfaces can limit the infiltration of foreign particles, thereby indirectly prolonging the lifespan of the diaphragm.
Technical Parameters:
| Model Number |
1261253 |
| Seat Material |
Nylon |
| Brand Name |
Taeha |
| Diaphragm Material |
NBR |
| Product Name |
Pulse Valve Diaphragm |
| Size Fitted Pulse Valve Port |
3/4'' |
Applications:
The Taeha Pulse Valve Diaphragm is an essential component designed for use in various industrial applications where efficient and reliable pulse valve operation is critical. This product is widely utilized in dust collector systems, pneumatic conveying systems, and other automated machinery that require precise control of airflow. The diaphragm, made from high-quality NBR (Nitrile Butadiene Rubber), ensures excellent durability and resistance to wear, making it an ideal choice for long-term use in harsh environments.
One of the primary application occasions for the Taeha Pulse Valve Diaphragm is in dust collector maintenance. Over time, diaphragms in pulse valves can wear out or become damaged, leading to decreased performance or system failure. The Taeha Diaphragm repair kit serves as an effective maintenance kit, allowing technicians to replace worn diaphragms quickly and restore the valve’s functionality without needing to replace the entire valve. This makes it an invaluable tool for maintenance teams aiming to minimize downtime and maintain optimal system efficiency.
Additionally, this product is suitable for use in maintenance kits designed for routine inspection and servicing of pulse valves. The diaphragm’s seat material, nylon, contributes to a secure fit and reliable sealing, ensuring that the pulse valve operates smoothly and prevents air leakage. The size-fitted pulse valve port of 3/4'' makes it compatible with a wide range of standard pulse valve models, providing versatility in various industrial settings.
The Taeha Pulse Valve Diaphragm is CE certified, guaranteeing compliance with international quality and safety standards. The product is conveniently packaged in cartons and has a minimum order quantity of just one piece, catering to both small-scale repairs and large-scale maintenance projects. With a supply ability of 5000 pieces per month and a delivery time of 1-7 work days after payment, customers can rely on timely availability for urgent maintenance needs.
Payment terms are flexible, accepting T/T, Western Union, and PayPal, facilitating smooth transactions globally. Pricing is negotiable, allowing for tailored agreements based on order volume or specific customer requirements. In summary, the Taeha Pulse Valve Diaphragm is an indispensable component for pulse valve maintenance, providing high-quality, durable performance in various application scenarios, from routine upkeep using maintenance kits to emergency repairs with the diaphragm repair kit.
Packing and Shipping:
Product Packaging and Shipping for Pulse Valve Diaphragm
The Pulse Valve Diaphragm is carefully packaged to ensure its protection during transportation and storage. Each diaphragm is individually wrapped in anti-static and moisture-resistant material to prevent any damage or contamination.
The wrapped diaphragms are then placed in sturdy, high-quality cardboard boxes with adequate cushioning materials such as foam or bubble wrap to absorb shocks and vibrations. The boxes are sealed securely and labeled clearly with product information, handling instructions, and shipping details.
For bulk orders, multiple boxes are consolidated into wooden crates or reinforced cartons to provide additional protection. All packaging complies with international shipping standards to guarantee the diaphragm arrives safely at its destination.
Shipping options include air freight, sea freight, and express courier services, depending on the urgency and destination. Tracking information is provided for all shipments to ensure transparency and timely delivery.
